Professional equipment
Time：2022-11-02
Main uses:fine sulfur,raw sulfur,coal preparation,light chemical dehydration and sewage treatment.
| Model & Spec. | TNZ-1.8 | TNZ-3.6 | TNZ-6 | ||
| Tank size | Diameter | m | 1800 | 3600 | 6000 |
| Center deepness | m | 1800 | 1800 | 3000 | |
| Rake speed | min/r | 0.5 | 0.4 | 0.3 | |
| Trough volume | m3 | 4.47 | 18.31 | 84.82 | |
| Settlement area | 2 m | 2.55 | 10.2 | 28.3 | |
| Production capacity | T/24h | 1.3-5.6 | 5.22.4 | 62 | |
| Eectromaor | Model | Y90L-6 | Y90L-6 | Y90L-4 | |
| Power | Kw | 1.1 | 1.1 | 1.5 | |
| Dimensions | L | m | 2800 | 4000 | 6184 |
| W | m | 1800 | 3600 | 6000 | |
| H | m | 2000 | 3100 | 4653 | |
| Weight | t | 1.24 | 3.01 | 8.58 | |
| Model & Spec. | TNZ-9 | TNZ-12 | ||
| Tank size | Diameter | m | 9000 | 12000 |
| Center deepness | m | 3000 | 3500 | |
| Rake speed | min/r | 0.25 | 0.19 | |
| Trough volume | m3 | 190.85 | 395.84 | |
| Settlement area | 2 m | 63.6 | 113.1 | |
| Production capacity | T/24h | 140 | 250 | |
| Eectromaor | Model | Y132S-6 | Y132S-6 | |
| Power | Kw | 3 | 3 | |
| Dimensions | L | m | 10000 | 14000 |
| W | m | 9000 | 12000 | |
| H | m | 5367 | 5525 | |
| Weight | t | 6 | 8.5 | |
