应用范围 ：MSK-115A-S真空预封机可应用于软包装锂电池真空预封口工艺。本机设计紧凑，可放置到手套箱内使用，并可实现抽真空和加热封口功能。该设备工作腔室真空度保持度好，封口效果优质，电池成品平整度好。
产品型号 ：MSK-115A-S
上架时间 ：2018-11-20
产品尺寸 ：410mm×365mm×520mm
重量 ：约45KG
价格 ：￥ 38000.00
BF浮选机技术参数
| 型号规指 | 容积 | 槽体尺寸 | 叶轮直径 | 处理能力 | 电抓功率 | 单槽质量 |
| m3 | mm | mm | m3/min | kw | Kg | |
| BF-0.37 | 0.37 | 740x740x750 | 286 | 0.2-0.4 | 1.5/1.1 | 470 |
| BF-0.65 | 0.65 | 850x950x900 | 300 | 0.3-0.7 | 3/1.1 | 932 |
| BF-1 2 | 1.2 | 1050x1150x1100 | 450 | 0.6-1.2 | 5 5/11 | 1370 |
| BF-2.0 | 2 | 1400x1450x1120 | 500 | 1-2 | 7.5/1.1 | 1750 |
| BF-2.8 | 2.8 | 1650x1650x1150 | 550 | 1.4-3 | 11/1.5 | 2130 |
| BF-4 | 4 | 1900x2000x1200 | 650 | 2-4 | 15/1.5 | 2585 |
| BF-6 | 6 | 2200x2350x1300 | 700 | 3-6 | 18.5/1.5 | 3300 |
| BF-8 | 8 | 2250x2850x1400 | 760 | 4-8 | 30/1.5 | 4130 |
| BF-10 | 10 | 2250x2850x1700 | 760 | 5-10 | 30/1.5 | 4660 |
| BF-16 | 16 | 2850x3800x1700 | 850 | 8-16 | 37/1.5 | 8320 |
| BF-20 | 20 | 2850x3800x2000 | 850 | W-20 | 37/1.5 | 8670 |
| BF-24 | 24 | 3150x4150x2000 | 920 | 12-24 | 45/1.5 | 8970 |
GF浮选机技术参数
| 型号规格 | 容积 | 槽体尺寸 | 安装功率 | 处理能力 | 刮板电机身率 | 空气吸入量 | 单槽质量 |
| m3 | mm | kw | m3/min | kw | m3/m2min | kg | |
| GF-0.35 | 0.35 | 700x700x730 | 1.5 | 0.1-0.2 | 0.75 | 1.2 | 470 |
| GF-0.7 | 0.7 | 900x900x900 | 3 | 0.1-0.4 | 1.1 | 1.2 | 932 |
| GF-1.1 | 1.1 | 1100x1100x1000 | 5 | 0.2-0.5 | 1.1 | t.2 | 1370 |
| GF-2 | 2 | 1400x1400x1150 | 7.5 | 0.3-1.0 | 1.5 | 1.2 | 1750 |
| GF-3 | 3 | 1500x1850x1200 | 11 | 0.5-1.5 | 1.5 | 1.2 | 2230 |
| GF-4 | 4 | 1600x2150x1250 | 15 | 0.5-2 | 1.5 | 1.2 | 2585 |
| GF-6 | G | 2000x2500x1300 | 22 | 1-3 | 1.5 | 1.2 | 3300 |
| GF-8 | 8 | 2200x2900x1400 | 30 | 1-4 | 1.5 | 1.2 | 4130 |
| GF-10 | 10 | 2200x2900x1700 | 30 | 2-6 | 1.5 | 1.2 | 4500 |
| GF-16 | 15 | 2850x3800x1700 | 45 | 3-8 | 2.2 | 1.2 | 8320 |
| GF-20 | 20 | 2850x3800x2000 | 45 | 4-10 | 2.2 | 1.2 | 8670 |
| GF-24 | 24 | 3150x4150x2000 | 55 | 5-12 | 2.2 | 1.2 | 8970 |
| GF-28 | 28 | 3150x4150x2300 | 55 | 5-14 | 2.2 | 1.2 | 9480 |
| GF-42 | 42 | 3600x4800x2650 | 75 | 8-20 | 3 | 1.2 | 19400 |
浮选机技术参数
| 型号规格 | 容积 m3 | 槽体尺寸 mm | 叶轮直径 mm | 叶轮转速 r/mm | 处理能力 m³/min | 电机功率 kw | 单槽质量 kg |
| XCF/KYF-1 | 1 | 1000x1000x1100 | 400/340 | 358/281 | 0.2-1 | 5.5/4/1.1 | 920/1056 |
| XCF/KYF-2 | 2 | 1300x1300x1250 | 470/410 | 331/247 | 0.4-2 | 7.5/5.5/1.1 | 1158/1346 |
| XCF/KYF-3 | 3 | 1600x1600x1400 | 540/480 | 266/219 | 0.6-3 | 11/7.5/1.5 | 2172/2074 |
| XCF/KYF-4 | 4 | 1800x1800x1500 | 620/550 | 215/200 | 1.2-4 | 15/11/1.5 | 2375/2100 |
| XCF/KYF-6 | 6 | 2050x2050x1750 | 620/550 | 215/200 | 3-6 | 15/11/1.5 | 3545/3278 |
| XCF/KYF-8 | 8 | 2200x2200x1950 | 720/630 | 185/175 | 3-8 | 22/15/1.5 | 4142/3857 |
| XCF/KYF-10 | 10 | 2400x2400x2100 | 760/660 | 185/175 | 3-10 | 22/15/1.5 | 4894/4334 |
| XCF/KYF-16 | 16 | 2800x2800x2400 | 860/740 | 160 | 4-6 | 37/30/1.5 | 6928/7575 |
| XCF/KYF-20 | 20 | 3000x3000x2700 | 910/780 | 160 | 4-20 | 37/30/1.5 | 9200/8240 |
| XCF/KYF-24 | 24 | 3100x3100x2900 | 950/800 | 153 | 4-24 | 37/30/1.5 | 10819/9820 |
| XCF/KYF-30 | 30 | 3500x3500x3025 | 880/900 | 140 | 40-30 | 45/37/1.5 | 14810/13820 |
| XCF/KYF-38 | 38 | 3600x3600x3400 | 1050/880 | 138 | 10-38 | 45/37/1.5 | 16900/16300 |
| XCF/KYF-40 | 40 | 3800x3800x3400 | 1050/1050 | 138 | 10-40 | 45/37/1.5 | 18790/17097 |
| XCF/KYF-50 | 50 | 4400x4400x3500 | 1200/1030 | 134 | 10-40 | 90/75/1.5 | 22000/22000 |
| 性能参数 / 型号 | XJ1 | XJ2 | XJ3 | XJ6 | XJ11 | XJ28 | XJZ11 | SF0.37 | SF0.65 | SF1.2 | SF2.8 | SF4 | SF8 | |
| 容积m3 | 0.13 | 0.23 | 0.35 | 0.62 | 1.1 | 2.8 | 1.1 | 0.37 | 0.65 | 1.2 | 2.8 | 4 | 8 | |
| 矿浆汁生产能力m³/min | 0.05-0.16 | 0.12-0.28 | 0.18-0.4 | 0.3-0.9 | 0.5-1.5 | 1.56-3.5 | 0.5-1.5 | 0.2-0.4 | 0.35-1 | 0.6-1.6 | 1.5-3.5 | 2-4 | 4-8 | |
| 空气吸入量m³/㎡min | 0.25 | 0.35 | 0.5 | 0.9-1 | 0.9-1.1 | 2.5 | 0.95-1.1 | 0.8-1 | 0.9-1 | 0.9-1.1 | 1-1.2 | 1-1.2 | 0.9-1 | |
| 传动电机 | 功率kw | 0.75 | 1.5 | 2.2 | 3 | 5.5 | 11 | 5.5 | 3 | 4 | 7.5 | 15 | 15 | 30 |
| 转速r/min | 1400 | 1430 | 1400 | 960 | 960 | 970 | 960 | 1410 | 960 | 960 | 970 | 730 | 730 | |
| 刮板电机 | 功率kw | 0.55 | 0.55 | 0.55 | 1.1 | 1.1 | 2.2 | 1.5 | 0.55 | 1.1 | 1.1 | 2.2 | 3 | 4 |
| 转速r/min | 1390 | 1390 | 1390 | 1400 | 1400 | 1400 | 1400 | 1390 | 1400 | 1400 | 1400 | 1400 | 1400 | |
| 叶轮 | 直径mm | 200 | 250 | 300 | 350 | 500 | 600 | 500 | 280 | 300 | 450 | 550 | 650 | 760 |
| 转速r/min | 600 | 500 | 470 | 400 | 350 | 280 | 330 | 380 | 400 | 320 | 268 | 220 | 191 | |
| 槽体尺寸（长*宽*高）mm | 500X500 | 600X600 | 700X700X | 900X900 | 1100X1100 | 1750X1600 | 1100X1100 | 700X700 | 900X900 | 1100X1100 | 1700X1600 | 1850X2050 | 2200X2900 | |
| X550 | X650 | 750 | X850 | X1000 | X1100 | X1000 | X750 | X900 | X1100 | X1150 | X1200 | X1400 | ||
